The PhotonTek Digital Light Controller is a full-control LED fixture master panel that allows you to control the full power of your entire LED lighting.

This smart-feature controller monitors and helps maintain optimal environmental conditions for the best growth and yield.

High-Tech Control

This user-friendly controller is a twin channel model, giving you the ability to control individual "zones" (channels) capable of operating up to 50 LED fixtures each.

Using an analog 0–10 V signal, each zone can either control the same-powered LED drivers or be set up to control different-powered LED drivers in each zone. For example, zone A can control 465 W LED fixtures, and zone B can control 600 W LED fixtures.

Key Features

• Control up to 100 LED Drivers
• Compatible with PhotonTek Fixtures
• Light Timing
• 24-hour Light Scheduling & Switching, Sunrise/Sunset Simulation
• Temperature Control for Safety (Dimming & Switching)
• Automate Light Intensity for control of PPFD totals for specific times
• Accurate Dimming in 1% Increments

Specification Highlights

• Power Dimming Range: 0%; 10%-100%
• Power Regulation Accuracy: 1%
• Temperature-controlled Safety Dimming Range: 32° to 104° Fahrenheit
• Temperature-controlled Safety Switching Range: 50° to 122° Fahrenheit
• Sunrise and Sunset Duration: 0-30 minutes

Summary

The PhotonTek Digital Lighting Controller is a full LED fixture master panel that can control up to 100 LED fixtures (same or different power) over two channels. Control light timing, sunrise/sunset, temperature safety, and automatic light intensity.
